Project Description
PETRO-ACC as an experienced supplier of Bitumen VG 30 would be one of the main suppliers of this kind of Bitumen in the Middle East and would be able to supply clients with competitive prices and different kinds of packings
| Name | Bitumen VG 30 |
| Manufacturer | PETRO-ACC |
| Made By | Aras Petrochemical Company |
| Product Code | VG 30 |
BITUMEN VG 30 MSDS
Table scrolling horizontally
| Material Safety Data Sheet of Bitumen VG30 | |
| Product Name | Bitumen |
| Catalog Codes | APC210 |
| CAS# | 8052-42-4 |
| Color: | Dark Brown |
| Odor: | Asphaltic |
| Odor Threshold -ppm: | NA |
| pH: | NA |
| Boiling point °C: | NA |
| Hazards Identification |
|
| First Aid Measures |
|
| Fire-Fighting Measures |
|
Table scrolling horizontally
BITUMEN VG 30 FEATURES
Bitumen VG 30 technical details
This kind of Bitumen will grade according to its viscosity and because of that its name would be including VG its viscosity will test at a temperature of 60 C°, its Penetration would be 50-70 and its flash point would be 220 C°.
Bitumen VG 30 Applications
This type of bitumen main used would be in Road construction in temperate countries but it is used in producing Liquid Bitumen, building insulation, and construction of sidewalks that bear heavy traffic loads too.
Bitumen VG 30 Packing
Packing of This type of bitumen VG would be 180 kg new steel drums.
BITUMEN VG 30 SPECIFICATION
| SPECIFICATION | TEST METHOD | A.S.T.M. |
| ABSOLUTE VISCOSITY, 60 C°, POISES
KINEMATIC VISCOSITY, 135 C°, CST, VISCOSITY RATIO AT 60 C° SPECIFIC GRAVITY AT 25/25 DEG C |
3200
370 2.18 1.017 |
D-2171
D-2170 D-2171 D-70 |
| PENETRATION AT 25 DEG C, 0.1 MM | 58 | D-5 |
| SOFTENING POINT DEG C° | 49.2 | D-36 |
| DUCTILITY AT 25 C°, CM | 125 | D-113 |
| FLASH POINT DEG C | 304 | D-92 |
| SOLUBILITY IN CCL4, %WT | 99.7 | D-2042 |
| LOSS ON HEATING, WT% | 0.08 | D-6 |
